Innokin Proton Plex Kit, New Plex Tank

Currently Out Of Stock

(3 reviews)
Write a Review
Selected Colour is
In Stock

Innokin Proton Plex Vape Kit

New Proton Plex Tank with Plexus Scion Coils

The new Innokin Proton and Plex vape tank combination is a classic. The Plex kit comprises the powerful Proton mod with all its features including new Atheon chipset, full colour TFT display, joy stick navigation, TCR and fast-charging functionality. In addition, Innokin have created the new Plex tank that is an ideal partner for such a great mod. The tank is next gen and designed to benefit from the new Plexus mesh coil innovation. The Plex combines dual bottom-adjustable airflow with an easy slide top-fill system and is fitted with new 0.13-ohm triple-core Plexus coil and comes with full Innokin warranty.

Proton Plex description

The Plex tank features an intuitively designed retractable top-cap which and comes equipped with a colour-coordinated resin drip tip. The PLEX kit includes the newest coil, the 0.13 ohm Plexus. The triple-core Plexus has three coils instead of one to give you enhanced vapour production, a richer flavour and greater longevity.

Innokin Proton Plex UK kit content

  • 1 x Proton Mod
  • 1 x PLEX Tank (0.13 ohm coil)
  • 1 x Plexus Scion Coil (0.15 ohm)
  • 1 x Micro USB Charging Cable
  • 1 x Spare Glass
  • 1 x Spare O-ring Set
  • 1 x Vape Band
  • 1 x User Packet (Quick Start Guide, QR Card, Warranty Card, Warning Booklet, Battery Warning Card)
  • 1 x Spare Glass
  • 1 x Spare O-ring Set
  • 1 x Vape Band
  • 1 x User Manual

Innokin Proton features and specifications

  • Height: 85 mm
  • Length: 44.6 mm
  • Width: 29.6 mm
  • Atomizer Resistance Range: 0.05 ohm – 3.5 ohm
  • Maximum Charge Current: 2 A
  • Maximum Output Current: 40 A
  • Minimum / Maximum Wattage: 6.0 W–235 W
  • Minimum / Maximum Voltage: 0.0 V–9.0 V
  • Temperature Control range: 150℃–315℃

Plex vape tank details

  • 54 mm X 24 mm
  • 2 ml vape juice capacity
  • Pyrex glass, Stainless steel body
  • Compatible with both Plexus and Scion coils
  • Fitted 0.13 ohm triple-core Plexus coil
  • Spare Plexus Scion 0.15 ohm coil

TFT screen Menu Items

  • > Coil
  • > TCR
  • > Curve
  • > Bypass
  • > Settings

Proton TFT screen and design

The Innokin Proton Plex TFT screen features an easy-to-read menu and features 5 info-lines that show wattage, mode, dual battery indicator level for each cell, resistance, coil type and puff time. The Innokin Proton  uses the standard 510 connection and on the side, the oversized hidden fire button is beautifully integrated into the design. The shell is contoured for a very smooth to the touch feel and the Innokin Proton is easy to operate using a well designed combination of USB port, TFT screen and the mouse/joystick.

Innokin Proton Plex quick start guide

The Proton Plex is aimed at the advanced vape user market and as such benefits those who are looking for big clouds and have a general knowledge of how vape mods work. However getting started in simple mode is quick and easy. If you don't need all the functionality of an advanced vape mod you may be better off with one of our straight forward vape pens and e cigarettes.

proton plex guide 1

proton plex guide 2


proton plex guide 3


 proton plex guide 4



Our pure organic tested VSAVI VG e-liquid is specially formulated to be less viscous and therefore can be used with Box Mods. Pure 100% VG, no dilution, no compromise!

Note: This is a sub ohm device, generally use only 0.3 or 0.6 mg strength nicotine.


Your Innokin Plex device is manufactured with precision so will not leak providing you use the product and parts correctly. Where any leaks have occurred, we have solved almost all by taking the following steps.

  • When using the Innokin Proton and Plex vape tank for the first time ensure all the parts of your tank are tightened properly, this involves finger tightening then an extra 1/16th turn
  • Ensure the O-ring seals are correctly in place
  • Make sure the coil in the tank is finger tightening then an extra 1/16th turn
  • When cleaning or replacing the Plexus coil carry out the above procedures.
  • Ensure you have the correct temperature/power settings for your particular device. Coils for example have ratings and should be kept within maximum and minimum recommended settings. Too high and your device will pop and crackle which may cause spots of e liquid to escape via the air-intake.

Where product has been returned, we have found that TIGHTENING the PIECES properly resolves any leak issue.

ABOUT Innokin

Founded in 2011 with their main factory of 10,000 square meters in Shenzhen, China and service and repair operations in California, Innokin is one of the leading electronic cigarette and vape device manufacturers in the world.

Innokin is known worldwide for leading brands such a Cool Fire, iClear, iTaste, Proton and Lily. Innokin is constantly at the forefront of innovations in electronic cigarette design and function and with over 150 patents. Innokin is accepted as an international pioneer. The advent of the classic Cool Fire 4 put them firmly on the map and now with the introduction of this ground-breaking Proton Plex Innokin is set to continue as a world leader. The Innokin Proton Plex is set to be the UK's leading high specification vape mod. Proton Plex reviews are now on-line and are outstanding!

Detailed Proton Plex design features

Plex proton kit design



Innokin Proton Plex User Manual


Innokin Proton Plex User Manual
